I am looking to add gable accents beyond vents such as corbels, millwork, gable pediments, etc. Is there way to place these sort of details into our 3-D models?



#2 Keith Almond

Keith Almond

    Advanced Member

  • Members
  • PipPipPip
  • 4,290 posts
  • LocationBrockville, Ontario, Canada

Posted 25 November 2015 - 12:27 PM

Yes, but you will have to be a little more specific in your requirements.



If you edit the wall, you can add a frieze board directly to the wall. The corbels and millwork etc, would be added as a symbol on the plan, and height adjusted accordingly. You can add pretty much anything you can conceive to the 3D models, although in a lot of cases, you will have to design the relevant elements yourself.








  • Yvon Gonthier likes this
Keith

There are 10 types of people in this world ....... Those who understand binary, and those who don't.

Softplan user since version 5.5.2.5

www.homehardwarekingston.ca

#3 Bob Billings

Bob Billings

    Newbie

  • Members
  • Pip
  • 3 posts
  • LocationGainesville, GA

Posted 01 June 2016 - 02:50 PM

What's the best way to draw a gable pediment?



#4 randolph cohn

randolph cohn

    Advanced Member

  • Members
  • PipPipPip
  • 869 posts
  • Locationmarin county - california

Posted 01 June 2016 - 06:35 PM

as mentioned, their are many types of pediments and of course designs.



your probably looking for something custom.



that you might have to create from shapes that you draw and than

turn that into a "solid polygon" and than open it in softview and

export it.

than a few more steps to make it into a softplan 3d model so

it'll stands up tall to place on the gable.



you can add 3d symbols to the solid polygons you add

plus so many stock items in softplan.



can you show us an image of what your after or something

that's close to it.



a little off track but we also have pediments for doors and windows already created



see the illustration for how to get it to show.



left click to enlarge



EDIT the opening and left click on the "exterior trim" tab



door pediment.JPG


randy

v10 to future 2016+ ;)


#5 Tom Rogers

Tom Rogers

    Advanced Member

  • Members
  • PipPipPip
  • 1,158 posts
  • LocationVilla Rica, Georgia

Posted 01 June 2016 - 06:50 PM

Somewhat on a side note, is there anyone that creates these 3D images and wants to sell their stock or create custom ones? Claude Poirer(sp) did this for me a while ago but no longer can find him.  If interested send me a private message.  Thanks.



Also be willing to get mentored in how to do it (teach a man to fish...  :P )


"remember... what we are building today, should be what we want in the future"​
Version 10 to Version 2016+ and beyond
www.residentialproductions.com

www.arcresidential.com




#6 Keith Almond

Keith Almond

    Advanced Member

  • Members
  • PipPipPip
  • 4,290 posts
  • LocationBrockville, Ontario, Canada

Posted 02 June 2016 - 06:28 AM

I thought that I'd already given you a tutorial .... Did that not work?



Just joking ... What is it that you are looking for Tom?


Keith

There are 10 types of people in this world ....... Those who understand binary, and those who don't.

Softplan user since version 5.5.2.5

www.homehardwarekingston.ca

#7 Tom Rogers

Tom Rogers

    Advanced Member

  • Members
  • PipPipPip
  • 1,158 posts
  • LocationVilla Rica, Georgia

Posted 02 June 2016 - 06:32 AM

That did Keith, thank you,  but I am looking into getting more detailed like corbals, brackets, etc.  More with creating and marrying through sketch-up and Softplan.  Most customers have custom brackets that I sketch but I don't have anything to show them in 3D.  I usually say "something like this".  but woudl also like to do exterior lights and such when they see or buy something they like


"remember... what we are building today, should be what we want in the future"​
Version 10 to Version 2016+ and beyond
www.residentialproductions.com

www.arcresidential.com




#8 Keith Almond

Keith Almond

    Advanced Member

  • Members
  • PipPipPip
  • 4,290 posts
  • LocationBrockville, Ontario, Canada

Posted 02 June 2016 - 06:46 AM

Softplan's downside is that 3D objects are not much more than extruded 2D shapes - although these work fine in most cases - getting true 3D can be complex. If you can use Sketchup, then you can create a more artistic 3D representation, but then once you get into complex shapes, that is normally above the capabilities of an entry level Sketchup user, and requires real talent - which I don't have.


Keith

There are 10 types of people in this world ....... Those who understand binary, and those who don't.

Softplan user since version 5.5.2.5

www.homehardwarekingston.ca

#9 admin

admin

    Administrator

  • Administrators
  • 88 posts

Posted 02 June 2016 - 08:51 AM

For corbels be sure to check the Osborne Wood Products in the SoftPlan+ manufacturers library.


  • Tom Rogers likes this
